Fusion was developed primarily for EPS/Epoxy surfboards; however the system can be just as easily applied to PU/Poly construction surfboards. Our goal in designing Fusion was to offer significant improvements and advantages over other pre-glass systems currently on the market.
STRENGTH
Fusion is the strongest pre-glass system on the market. This was achieved by incorporating a figure eight outline which provides constant curves to prevent the straight line shearing that fibreglass is prone to. We also incorporated a high density foam foundation under the plug to dramatically increase the impact resistance and break strength, while providing a solid base so the plug does not rotate or sink into the foam.
Note: The strength of other pre-glass systems is reliant on the strength of the actual foam blank and the fibreglass and resin covering the flange of the plug. Generally surfboard blanks do not provide the strength required to support the lateral forces experienced under load. This causes other systems to sink into the foam causing the fibreglass above the system to crack.
WEIGHT
FCS Fusion has proven to be the lightest pre-glass fin system available. Minimising the installed weight of the system ensures the natural balance of the board is never compromised.
SIZE
FCS Fusion has a shorter footprint than other pre-glass systems allowing the tail of the board to flex naturally. Tail flex is very important because it not only gives the board a livelier more responsive feel, but also helps create speed and makes the board more forgiving by adjusting to the curve of the wave and the arc of your turns. With Fusion, the smaller footprint also gives the side fins greater clearance from the rail of the board making installation easier, and ensuring fi n positions are never compromised.
ACCURACY
Shapers spend considerable time on fin placement so we feel it’s very important to see the shapers dots as they tell you at a glance that the fin system has been installed accurately. We know that a slight variation in fin placement can make a big difference to how your board performs. While other box systems require the removal of the shapers dots, FCS Fusion does not.
CANT ANGLES
FCS Fusion comes available in three different cant angles; 0 degrees, 5 degrees and 9 degrees. Choosing the correct cant angle makes it easy to obtain the desired fin position while adjusting to suit both extreme and subtle bottom contours. This allows for a stronger installation with accurate fin cant angles every time.
ADJUSTABILITY
FCS Fusion plugs have slightly elongated fin slots. This allows for slight forward and aft fin adjustment for surfers who want to fine-tune the performance of their board.
Brand
FCS Surf Essentials
FCS USA is the leader in surfboard fins, covers, traction, leashes and surf accessories. 67 WSL World Championship Tour events have now been won by surfers riding FCS.
THERE ARE MANY ASPECTS TO SURFBOARD SELECTION THESE ARE THE POINTS TO CONSIDER
LENGTH
Typically surfboards are measured in inches. The length is measured from the nose to the tail. Choosing the length of the surfboard is dependant on your size (weight, height), board type and waves conditions you wish to use the board for.
WIDTH
The widest point of the surfboard is measured from rail to rail. Generally the wider the surfboard the more stable the board, while a board with smaller width maintains better speed and performance.
BOARD THICKNESS
Surfboard thickness is measured from the top deck to the bottom. The thickness again has a bearing on the board’s performance. Professional surfers will tend to go for the thinner boards as they are lighter and offer better performance.The thicker boards are stronger and because there is more foam under the surfer the boards are more stable.
ROCKER
The bottom curve of a surfboard. Generally the more rocker the surfboard has the more loose (manoeuvrable) the surfboard will be. Where the flatter rocker surfboards will be faster, although they will lack the looseness. The nose is the tip of the surfboard, the nose can vary in shapes and size. Basically the thinner the nose the more response the board will perform, while wider noses are better for stabilization.
STRINGER
Used to increase the strength of a surfboard, a stringer (normally made from wood) runs down the length of a surfboards (typically in the centre of the board from the tip of the nose to the tail).
Boards built with Epoxy, Carbon Fibre and soft boards generally don’t have stringers.
FINS
Generally heavier surfers require larger fins to hold the waves better. Although if you prefer to ride a looser (less hold in the waves), smaller fins would be a better option.
FIN CONSIDERATIONS
Fin configurations have an effect on the ways your surfboards perform.
The following are some of the more common fin configurations.
SINGLE FIN
The single fin was the original fin configuration for surfboards. Based on the idea of the sailboat keel. Single fins are added stabilization and control on the powerful, larger waves, although lack manoeuvrability
TWIN FIN
Are great for small waves, being fast and manoeuvrable, but when put into tight spots on larger waves, they become hard to control. Popular with Fish surfboards.
THRUSTER 3 FIN
Widely recognized as the standard fin configuration, the thruster answers the shortcomings of the single fin and the twin fins configurations.
The thrusters give you stabilization, control and manoeuvrability in all types of surfing conditions.
This concept was the brainchild of Australia’s Simon Anderson
QUADS 4 FINS
With four fins in the water, Quads boasts an extraordinary amount of holding power in larger surf.
You may think that having four fins would sacrifice speed by creating more drag, but this is not the case.
The both sets of fins are working together on the rail, which makers believe they creates less drag than a board with a centre fin.
The manoeuvrability isn’t sacrificed either, with fins directly under your back foot, the quads are very responsive.
KEEL
Similar setup to the Twin Fin, although smaller (low profile) fins are generally placed wider (closer to the rails) on the surfboard.
Popular with Fish and Egg / Retro surfboards.
